| 到付 | 刷卡 | 現金 | 文章 | 留言 | 議價 |
|---|---|---|---|---|---|
| 16,290 | 16,290 | 16,020 | 留言 | 議價 |
| 即時貨況： |
|
||||||||||||
| 產品編號： | W56132.8431.E2242.A82 | ||||||||||||
| 品名： | ioLogik E2242 | ||||||||||||
| 廠牌： | MOXA | ||||||||||||
| 名稱： | |||||||||||||
| 簡規： | Smart Ethernet remote I/O with Click&Go , 4 AIs , 12 DIOs/ ;/ ;/ ;/ ;/ ; | ||||||||||||
| 規格： |
|
||||||||||||
| 詳細內容： | • ioLogik E2242 Specifications • Inputs and Outputs Configurable DIOs (by software) 12 channels Analog Inputs 4 channels Isolation 3k VDC or 2k Vrms • Digital Input Sensor Type Wet Contact (NPN or PNP) and Dry Contact I/O Mode DI or Event Counter Dry Contact • On: short to GND • Off: Open Wet Contact (DI to GND) • On: 0 to 3 VDC • Off: 10 to 30 VDC Common Type 6 points per COM Isolation 3k VDC or 2k Vrms Counter Frequency 900 Hz Digital Filtering Time Interval Software selectable • Digital Output Type Sink I/O Mode DO or Pulse Output Pulse Output Frequency 1 kHz Over-Voltage Protection 45 VDC Over-Current Protection 2.6 A (4 channels @ 650 mA) Over-Temperature Shutdown 175°C (min.) DIO Output Leakage Current 4.0 mA @ 24 VDC Current Rating 200 mA per channel • Analog Input Type Differential input Resolution 16 bits I/O Mode Voltage / Current (software selectable) Input Range ±150 mV, 0 to 150 mV, ±500 mV, 0 to 500 mV, ±5 V, 0 to 5 V, ±10 V, 0 to 10 V, 0 to 20 mA, 4 to 20 mA Accuracy ±0.1% FSR @ 25°C ±0.3% FSR @ -10 and 60°C ±0.5% FSR @ -40 and 75°C Sampling Rate All channels: 32 samples/sec Per channel: 8 samples/sec Single channel: 100 samples/sec Input Impedance 200 kilo-ohms ohms (min.) Built-in Resistor for Current Input 120 ohms • Power Requirements Input Voltage 12 to 36 VDC Input Current 178 mA @ 24 VDC • MTBF (mean time between failures) Time 204,391 hrs Standard Telcordia SR332 • Common Specifications • LAN Ethernet 1 10/100 Mbps RJ45 port Protection 1.5 kV magnetic isolation Protocols Modbus/TCP (slave), TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP • Serial Interface 1 RS-485-2w terminal block port Parity None Data Bits 8 Stop Bits 1 Flow Control None Baudrate 1200 to 115200 bps Protocols Modbus RTU (gateway) • Physical Characteristics Wiring I/O cable max. 14 AWG Dimensions 115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in) Weight under 250 g (0.55 lb) Mounting DIN-rail or wall • Environmental Limits Operating Temperature Standard Models: -10 to 60°C (14 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) Storage Temperature -40 to 85°C (-40 to 185°F) Ambient Relative Humidity 5 to 95% (non-condensing) Shock IEC 60068-2-27 Vibration IEC 60068-2-6 Altitude Up to 2000 m Note Please contact Moxa if you require products guaranteed to function properly at higher altitudes. • Standards and Certifications Safety UL 508 EMC EN 61000-6-2/6-4 EMI CISPR 22, FCC Part 15B Class A EMS IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m 1.4 GHz to 2 GHz: 3 V/m 2 GHz to 2.7 GHz: 1 V/m IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV IEC 61000-4-5 Surge: Power: 1 kV IEC 61000-4-6 CS: 10 V IEC 61000- Green Product RoHS, CRoHS, WEEE Note Please check Moxa’s website for the most up-to-date certification status. • Warranty Warranty Period 5 years |
||||||||||||
| 即時資訊： |
|
||||||||||||
| 好康報報： |
|
||||||||||||
| 賣場備註： |
尚興資訊有限公司(店面經營跟網路販售均有十年以上，歡迎指教) ＊外島寄送運費另計(以各物流差價貼補)，謝謝＊ 於本賣場購買的各種優點(跟其他賣場比較時，別忘了同時比較是否能提供這些服務
◎更新速度快(商品每工作日更新，更新價格跟商品，可買到最新上市商品最新價格) ◎七天內如新品故障，本島來回運費本賣場付擔(非其他賣場，運費都要由買家支付) ◎即時貨況查詢，較不會有下標後，拿不到貨的情形(提供更即時，更方便購物環境) ◎實體店面經營(店面提供你更優良的售後保固，不用擔心商品來源不明，更有保障) ◎堅持商品為全新未拆，未使用過新品出貨(不用擔心拿到的會是二手品，展示品等) ★本島寄送免運費(外島運費需另計)，請注意尚餘數量並非供貨數量，量多請詢問★ 寄送方式說明:
◎寄送方式為賣場統一設定，而大件商品無法使用超商寄送或是郵局寄送，請注意． ◎貨到付款訂單，會電話確認(超大商品或特殊商品或負評等棄標過多，恕不接受)． ◎可於24小時寄達之商品，需同時符合以下四項條件，才可能於24小時(隔日)寄達． A:需為非假日購買(營業時間:週一至週五-10:00~18:00-例假日跟國定假日均無出貨)． B:即時貨況最大字文字內容為有貨供應請購買或現貨供應請購買或廠商有貨請購買． C:使用轉帳或刷卡並選擇快遞寄送且寄送地點非偏遠地區(非花東地區或偏遠的地區)． D:需下午五點前完成交易並給寄件資料(即時貨況為廠商有貨請購買需下午三點前)．
1.販售商品是台灣代理商貨/公司貨? 2.商品如何保固？
5.如何購買商品?(如於五工作天內無法出貨商品，會去電或去信通知是否需取消交易)
7.為何相同賣場的相同商品價格不同?
其他常見問題或補充說明，請看關於我或客服頁面． |
||||||||||||
